ClarityCap DTAC The DTAC range is a high performance addition to our range.

It has been designed to produce the lowest possible resistance within the component, which we believe has a direct relationship to sonic performance.

A narrow 10µm (630Vdc) polypropylene film with a special spray and heat treatment contribute to the exceptional performance of this capacitor. These measures combined with hand soldered M8 male or female terminations ensure that the ESR is greatly improved when compared to the traditional axial leaded components.

The low ESR is particularly relevant in high quality crossover networks, ensuring that loudspeakers perform to their optimum.

Tape and resin colours are flexible with options shown in Custom products. Unless specified, capacitors would be supplied with gold tape and black resin.

Technical details

Tolerance +/-5% standard. Others by request   Dissipation factor ≤ 0.001 @ 1 kHz, 20 °C
Rated voltage 630Vdc Insulation resistance ≥ 10 000 MΩ x µF / C, C>330nF
≥ 30 000 MΩ , C<330nF @ rated voltage, 20 °C
Dielectric absorption ≤ 0.1% @ 20 °C Proof voltage test 1.5 x rated voltage for 30s. Not to be repeated
Environmental category 55/100/56 to EN 60068 - 1 (IEC 68 - 1) Temperature range -55 to +100 °C


Selected pairs of capacitors (capacitance difference less than 1%) are available at an additional charge of EUR 2,80 excl. VAT: € 2.35 / $ 2.56

To connect the capacitor we offer a connection set with two screws and two crimp-type sockets EUR 0,97 excl. VAT: € 0.82 / $ 0.89

ClarityCap DTAC 630Vdc

Product ID C/µF U/Vdc Dimensions
DxL/mm
Price
cc-dtac22-630 2.2 630   EUR 34,40 excl. VAT: € 28.91 / $ 31.51
cc-dtac27-630 2.7 630   EUR 34,90 excl. VAT: € 29.33 / $ 31.97
cc-dtac30-630 3.0 630 45.0 x 27.0 EUR 65,00 excl. VAT: € 54.62 / $ 59.54
cc-dtac33-630 3.3 630   EUR 37,60 excl. VAT: € 31.60 / $ 34.44
cc-dtac39-630 3.9 630   EUR 36,60 excl. VAT: € 30.76 / $ 33.52
cc-dtac40-630 4.0 630 53.0 x 27.0 EUR 65,00 excl. VAT: € 54.62 / $ 59.54
cc-dtac47-630 4.7 630   EUR 48,00 excl. VAT: € 40.34 / $ 43.97
cc-dtac56-630 5.6 630   - not available
cc-dtac68-630 6.8 630   - not available
cc-dtac82-630 8.2 630   - not available
cc-dtac100-630 10.0 630 82.0 x 27.0 EUR 92,00 excl. VAT: € 77.31 / $ 84.27
cc-dtac120-630 12.0 630 89.0 x 27.0 EUR 101,00 excl. VAT: € 84.87 / $ 92.51
cc-dtac150-630 15.0 630 100.0 x 27.0 EUR 111,00 excl. VAT: € 93.28 / $ 101.67
cc-dtac180-630 18.0 630 109.0 x 27.0 EUR 125,00 excl. VAT: € 105.04 / $ 114.50
cc-dtac200-630 20.0 630 115.0 x 27.0 - not available
cc-dtac220-630 22.0 630 121.0 x 27.0 EUR 146,00 excl. VAT: € 122.69 / $ 133.73
